Standard Cutting Disc
Technical Data
- Application: Cutting of stainless steel and ferrous materials.
- Compatibility: Portable or bench machines.
- Standardization: Manufactured according to ABNT 15230 standard.
Available Specifications
External Diameter x Thickness x Bore Diameter
| Code | Dimensions | Packaging |
| FT4622 | 4 1/2″ x 3/64″ x 7/8″ | 25 discs |
| FT4624 | 7″ x 1/16″ x 7/8″ | 10 discs |
Benefits
- High Performance on Stainless Steel: Formulated to provide fast and clean cuts on stainless steel surfaces.
- Guaranteed Safety: Meets rigorous technical standards to prevent ruptures during operation.
- Versatility: Effective for both small repairs and larger-scale industrial applications.
Instructions for Use
- Positioning: The disc must be operated at a 90° angle to the workpiece to avoid twisting and ensure cutting safety.
- Verification: Before mounting, ensure that the disc shows no apparent cracks or damage.
- Rotation: Always respect the RPM limit indicated on the label, never exceeding the disc or machine capacity.
Health and Safety Information
- Required PPE: The use of safety glasses, protective gloves, dust mask and hearing protectors is essential.
- Machine Protection: Always use the original protective guard of the equipment during the entire operation.
- Standardization: For more details on safe handling, consult the ABNT NBR 15230 standard.
Storage and Disposal
- Storage Environment: The product should be kept in its original packaging, in a dry and ventilated location.
- Ideal Conditions: Recommended temperature between 15°C and 27°C, with relative humidity between 35% and 50%.
- Position: Store discs horizontally and away from floors, windows or damp walls.
